Features:
Angled Ventilation – The aggressive, angled front panel ventilation dons sharp design elements and striking lines, signifying the K501L’s competitive character.
Illuminated Fan & Power Button – Paired with lighting on the power button, an illuminated fan glows through the angled ventilation; a testament to its gamer core.
Top Panel Ventilation – For increased thermal performance, the top panel is ventilated to support cooling components and filtered to protect against dust.
Cooling Support – Support for up to 6 fans and top, front, and rear water cooling ensures a high capacity for thermal performance.
Edge-to-Edge Tempered Glass Side Panel – Showcase your build through the 4mm tempered glass side panel.
Clean Routing Space – There is 19~27mm width of space behind the motherboard tray to efficiently manage and organize cables.
Versatile Component Support – Clearances of 410mm for the graphics card, 165mm for CPU coolers, and 200mm for PSUs offer room for powerful builds and future upgrades.
Specifications:
| Model Number | MCB-K501L-KGNN-SR1 |
| Color | Black |
| Materials | Tempered Glass |
| Motherboard Support | Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*support for up to 12″ x 10.7″, will limit cable management features) |
| Expansion Slots | 7 |
| 5.25″ Drive Bays | 0 |
| 2.5″ / 3.5″ Drive Bays (combo) | 2 |
| 2.5″ Drive Bays | 4 (2+2 combo) |
| I/O Panel | 1x USB 3.0 Type-A, 1x USB 2.0, 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack |
| Pre-installed Fans – Top | N/A |
| Pre-installed Fans – Front | 1x 120mm RGB LED |
| Pre-installed Fans – Rear | 1x 120mm |
| Fan Support – Top | 3x 120mm, 2x 140mm |
| Fan Support – Front | 3x 120mm, 2x 140mm |
| Fan Support – Rear | 1x 120mm |
| Fan Support – Bottom | N/A |
| Clearance – CPU Cooler | 165mm/6.49″ |
| Clearance – PSU | 180mm/7.08″, 295mm/11.61″ (w/ HDD cage removed) |
| Clearance – GFX | 410mm/16.1″ |
| Cable Routing | 19mm/0.74″ |
| Dust Filters | Top, Front, Bottom |
| Power Supply Support | Bottom mount, ATX |
| Warranty | 2 Years |
